Innovative Solutions for RF & Microwave Components
Although all of G-WAY's amplifier modules may be re-configured into Systems, to get a better idea of what G-WAY has to offer, here is a selection of Top Selling System Configurations. To view system specification, please click on image, and click [Go to Link].
For a translation of Option Codes, please see the Master Option Page here:
G-WAY's Top Selling Amplifier System Configurations
 MP1300/200/50HK-R3U15The MP1300/200/50HK-R3U15 is an L-Band high power amplifier system for various applications. The amplifier system supports signal amplification in to 1200-1400 MHz frequency range and is appropriate for CW, FM, PM, AM, Digital and/or Pulse modulations. Options Included: R3U15, FHR, FPPS, RM9, 12V1, SMA/N, SSPO, SRR, COTR-P, ETHER/RS232) |  MP1850/2300/48MK-R2U13The MP1850/2300/48MK-R2U13 is a broadband high power amplifier for 700-3000 MHz applications. It is suitable for jamming or communication operations. The amplifier employs GaN power devices that provide ample output power, wide dynamic range and high efficiency. Options Include: R2U13, 12V1, N/N, SNF, FPGA, RM9, FPPS, FHR | MP500/1000/48MK-R3U13The MP500/1000/48MK-R3U13 is a high power amplifier for the 20-1000 MHz frequency band. The amplifier system employs MOSFET devices, is protected against over-temperature, over-driving, over-power and excessive current draw. Options Included: R3U13, CONTR, GUI, RS232, RM9, 12V1, FPPS, N/N SNB |
|---|---|---|
MP510/980/54HK-R3U15The MP510/980/54HK-R3U15 is a high power amplifier for the 20-1000 MHz frequency band. The amplifier system is protected against over-temperature, over-driving, over-power and excessive current draw. The amplifier employs GaN devices that provide ample output power, wide dynamic range and high efficiency. Options Include: R3U15, CONTR, GUI/RS232, 12V1, N/N, SNB FPPS | MP1750/1500/50MK-R3U15The MP1750/1500/50MK-R3U15 is a broadband high power amplifier system that supports signal amplification in the 1000-2500 MHz frequency range. The amplifier system is fed by AC 110/220VAC standard grid power. Options Include: R3U15, RM9, FPPS, SNB, 12V1, SSPO, SMA/N |  MP750/500/57HK-R4U17The MP750/500/57HK-R4U17 is a high power amplifier system that supports signal amplification in the 500-1000 MHz range and is protected against over-temperature, over-power, VSWR and excessive current draw. This amplifier is suitable for lab, jamming or communications applications. Options Include: R4U17, TOUCH, GUI, RS232, N/N, SSPI, SSPO, FPPS |
MA942-10/54HK-R3U13The MA942-10/54HK-R3U13 is a high power amplifier system for 925-960 MHz frquency band. It supports GSM/EDGE applications. The amplifier system is protected against over-temperature, over-power and excessive current draw. Options Included: R3U13, GUI, CONTR, RS232, FRRS, RM9, IALC, 12V1, N/N, SNB | MP1940/460/54HK-R3U15The MP1940/460/54HK-R3U15 is a high power amplifier for 1710-2170 MHz frequency band. The amplifier employs advanced GaN power devices that provide ample output power, wide dynamic range and high efficiency. Options Included: 3U15, CONTR, GUI, RM9, RS232, N/N, FPPS, 12V1 | MP1300/200/50HK-R3U15The MP1300/200/50HK-R3U15 is an L-Band high power amplifier system for various applications. The amplifier system supports signal amplification in to 1200-1400 MHz frequency range and is appropriate for CW, FM, PM, AM, Digital and/or Pulse modulations. Options Included: R3U15, FHR, FPPS, RM9, 12V1, SMA/N, SSPO |
 MP2140/60/57HK-R3U15The MP2140/60/57HK-R3U15 is a high power amplifier system for single and multi carrier application in AWS & UMTS bands for WCDMA high power linear applications. The amplifier employs linear LDMOS power devices that provide significant linear output power, wide dynamic range and high gain. Options Include: R3U15, FPGA, RM9, FPPS, 12V1, SNB, N/N |
